Products Description
SSR-40DA Single-Phase Solid State Relay - High Power Contact Load for High Protective Switch
Quantity
FOB Price
≥5000
US$ 1.16
2000–4999
US$ 1.18
≤1999
US$ 1.3
Product Attribute
Contact Form:
1NC
Contact Load:
Other
Max. switching current:
100 A
Rated Current:
Other
Place of Origin:
Zhejiang, China
Model Number:
SSR40DA
Brand Name:
FCGK
Max. switching voltage:
480 V
Power Source:
AC/DC
Protect Feature:
Sealed
Size:
Miniature
Terminal Shape:
Screw Terminal
Theory:
Solid State Relay
application:
General Purpose
Load Current:
10-120A
Load Voltage:
24-380VAC
Control Voltage:
3-32VDC,70-280VAC
Control current:
DC 3-25mA
On Voltage:
≤1.5V
Off Leakage Current:
≤2mA
On-off Time:
≤10mS
Dlelectric Stength:
2500VAC
Insulation Resistance:
1000MΩ/500VDC
Ambient temperature:
-30 ~+75℃
Packaging and delivery
Selling Units:
Single item
Single package size:
5X7X3 cm
Single gross weight:
0.150 kg
More
Sample Policy:
Free samples are available
